To Be Discontinued
Category Temperature Range
-40～70 ℃
Rated Voltage
7.5 Vdc
Capacitance
466 F
Capacitance Tolerance
+10% / -15%
Size W
54mm
Size D
186mm
Size H
172.6mm
Internal Resistance (Typ.)
3.6 mΩ
Internal Resistance (Max.)
4.2 mΩ
Energy Storage
?
The energy storage capacity [Wh] described
in this product is calculated based
on "Guidebook on Transportation of Supercapacitors
for Electrical and Electronic Equipment (JEITA)".
3.7 Wh
Reference Weight
?
This is a representing value calculated from a standard material composition.
Note that the reference weights are not considered as guaranteed value.
1.2 kg
RoHS Compliant
?
10 Restricted Substances 2011/65/EU and (EU) 2015/863
Compliant
Product Information
Project
Specifications
Temperature characteristics
Capacitance Change
≦±30% of the measured value at 20℃
(-40℃)
Internal Resistance Change
≦1200% of the internal resistance maximum value given in the ratings tables
Load Life Test
After the capacitors are subjected to the rated DC voltage at 70℃ for 2000 hours, the following specifications shall be satisfied when they are restored to 20℃.
Capacitance Change
≦±30% of the capacitance rated value given in ths ratings tables.
Internal Resistance Change
≦300% of the internal resistance maximum value given in the ratings tables
Bias Humidity Test
After the capacitors are left at 60℃ and 90 to 95%RH for 500 hours without voltage applied, the following specifications shall be satisfied when they are restored to 20℃.
Capacitance Change
≦±30% of the capacitance rated value given in ths ratings tables.
Internal Resistance Change
≦300% of the internal resistance maximum value given in the ratings tables
Insulation Resistance
The measured value between the lumped terminal and the case using 500Vdc insulation resistance meter shall be more than 100MΩ.
Insulation Withstand Voltage
No abnormality after the AC 2500V is applied between lumped terminal and package for 1 minute. package for 1 minute.
![Dimension [mm]](/products/edlc/images/MDXE7R5S461PB3111C_1.svg)
